Floor Scarifier CT320 Multi-use
In stock
The biggest and most aggressive floor planer/scarifier from CONTEC© now available with a 35 hp petrol engine.
Independent from a power supply. A generator is not necessary. Made for the hardest applications and floors. Heavy duty bearings ensure maintenance and trouble-free operation of the machine. CT 320 ® is equipped with a variable speed drive unit. Ergonomically designed handle bars ensure comfortable operation of the floor planer.
The CT 320® displays tremendous aggressiveness during the removal of concrete, asphalt, coatings and road markings. Milling cutters or diamond tools ensure problem free removal of flexible epoxy coatings and road markings. Specially designed diamond tools for use in “Farmyard Grooving“ result in anti-slip surfaces every time. Variable spacer systems permit any groove pattern.
Working Width
320/340 Diamanttrommel/Diamond Drum mm
Weight (kg): 267 kg
Dimensions:
Length (mm) 110 cm
Width (mm) 66 cm
Height (mm) 118 cm
Motor nominal Current (Drive Unit Motor): 0.17 kW
Motor nominal Current: 35 PS kW
If working dry we suggest using the TORNADO/R2D2 dust Collector. CT 320 Water Connection: The Water Connection enables the machine to spray water at the diamond blades. The water cools the tools and minimises the dust emission.
Motor Rating (Drive Unit Motor): 1.2 A
Motor Rotation Speed: 3600 rpm
Dust Port Diameter: 70/125 mm
Motor Rotation Speed (Drive Unit Motor): 3000 rpm
CT 320/340 Cutter Drum
CT 320/340 complete Cutter Drum
CT 320/340 Diamond Drum
The drum core of the CT 320/340 can be fitted with diamond saw blades - with spacers between the individual saw blades, (as shown in this illustration) slatted floors or anti-slip walkways in stables can now be re-cut or redesigned to increase safety. A denser configuration is perfect for grooving or restoring broom-like structures in worn or overly smooth concrete surfaces. If the drum is fully loaded, the floor is completely
removed. Cutting depths of 20 mm (standard version) are possible. The optional, integrated water flush cools the tools. A rear-wheel drive with electronic speed control ensures an optimal, clean cutting result.
